I trying to set up dual monitors Ubuntu 18.04 using the single HDMI port and the VGA port on my NUC5CPYH. I have had no luck so far. The BIOS screen doesn't display with VGA only port plugged in (NO HDMI) either. I have set the BIOS to use the VGA as the primary display and the doesn't seem to help.
I still get "no signal" on the monitor. Oddly enough when I plug it in ubuntu sees it and recognizes the monitor in the display setup. I can move the mouse(cursor) off screen to the right and it acts as if it is on the monitor(that is not displaying anything). The two monitors I am using are identical and I have swapped them to test and both work fine. They are Benq GW2280 monitors. I suspect it may be a driver issue.
Here is the information on the internal graphics card:
VGA compatible controller: Intel Corporation Atom/Celeron/Pentium Processor x5-E8000/J3xxx/N3xxx Integrated Graphics Controller (rev 21) (prog-if 00 [VGA controller]) Subsystem: Intel Corporation Atom/Celeron/Pentium Processor x5-E8000/J3xxx/N3xxx Integrated Graphics Controller Flags: bus master, fast devsel, latency 0, IRQ 125 Memory at 80000000 (64-bit, non-prefetchable) [size=16M] Memory at 90000000 (64-bit, prefetchable) [size=256M] I/O ports at f000 [size=64] [virtual] Expansion ROM at 000c0000 [disabled] [size=128K] Capabilities: [d0] Power Management version 2 Capabilities: [90] MSI: Enable+ Count=1/1 Maskable- 64bit- Capabilities: [b0] Vendor Specific Information: Len=07 <?> Kernel driver in use: i915 Kernel modules: i915 Any help would be appreciated.
Here is my xrandr --verbose output:
Screen 0: minimum 320 x 200, current 1920 x 1080, maximum 8192 x 8192 DP1 connected 1920x1080+0+0 (0x47) normal (normal left inverted right x axis y axis) 476mm x 268mm Identifier: 0x42 Timestamp: 348006 Subpixel: unknown Gamma: 1.0:1.0:1.0 Brightness: 1.0 Clones: CRTC: 1 CRTCs: 1 2 Transform: 1.000000 0.000000 0.000000 0.000000 1.000000 0.000000 0.000000 0.000000 1.000000 filter: _MUTTER_PRESENTATION_OUTPUT: 0 EDID: 00ffffffffffff0009d1e87845540101 141c01040e301b782e79a5a85551a227 105054a56b80d1c0b300a9c081808100 81c001010101023a801871382d40582c 4500dc0c1100001e000000ff00455441 354a3033373834534c30000000fd0032 4c1e5311000a202020202020000000fc 0042656e51204757323238300a20003c max bpc: 10 range: (6, 10) Broadcast RGB: Automatic supported: Automatic, Full, Limited 16:235 audio: auto supported: force-dvi, off, auto, on non-desktop: 0 range: (0, 1) link-status: Good supported: Good, Bad 1920x1080 (0x47) 148.500MHz +HSync +VSync *current +preferred h: width 1920 start 2008 end 2052 total 2200 skew 0 clock 67.50KHz v: height 1080 start 1084 end 1089 total 1125 clock 60.00Hz 1680x1050 (0x13a) 146.250MHz -HSync +VSync h: width 1680 start 1784 end 1960 total 2240 skew 0 clock 65.29KHz v: height 1050 start 1053 end 1059 total 1089 clock 59.95Hz 1600x900 (0x4e) 108.000MHz +HSync +VSync h: width 1600 start 1624 end 1704 total 1800 skew 0 clock 60.00KHz v: height 900 start 901 end 904 total 1000 clock 60.00Hz 1280x1024 (0x4f) 135.000MHz +HSync +VSync h: width 1280 start 1296 end 1440 total 1688 skew 0 clock 79.98KHz v: height 1024 start 1025 end 1028 total 1066 clock 75.02Hz 1280x1024 (0x50) 108.000MHz +HSync +VSync h: width 1280 start 1328 end 1440 total 1688 skew 0 clock 63.98KHz v: height 1024 start 1025 end 1028 total 1066 clock 60.02Hz 1280x800 (0x13b) 83.500MHz -HSync +VSync h: width 1280 start 1352 end 1480 total 1680 skew 0 clock 49.70KHz v: height 800 start 803 end 809 total 831 clock 59.81Hz 1152x864 (0x52) 108.000MHz +HSync +VSync h: width 1152 start 1216 end 1344 total 1600 skew 0 clock 67.50KHz v: height 864 start 865 end 868 total 900 clock 75.00Hz 1280x720 (0x53) 74.250MHz +HSync +VSync h: width 1280 start 1390 end 1430 total 1650 skew 0 clock 45.00KHz v: height 720 start 725 end 730 total 750 clock 60.00Hz 1024x768 (0x56) 78.750MHz +HSync +VSync h: width 1024 start 1040 end 1136 total 1312 skew 0 clock 60.02KHz v: height 768 start 769 end 772 total 800 clock 75.03Hz 1024x768 (0x57) 65.000MHz -HSync -VSync h: width 1024 start 1048 end 1184 total 1344 skew 0 clock 48.36KHz v: height 768 start 771 end 777 total 806 clock 60.00Hz 832x624 (0x58) 57.284MHz -HSync -VSync h: width 832 start 864 end 928 total 1152 skew 0 clock 49.73KHz v: height 624 start 625 end 628 total 667 clock 74.55Hz 800x600 (0x59) 49.500MHz +HSync +VSync h: width 800 start 816 end 896 total 1056 skew 0 clock 46.88KHz v: height 600 start 601 end 604 total 625 clock 75.00Hz 800x600 (0x5a) 40.000MHz +HSync +VSync h: width 800 start 840 end 968 total 1056 skew 0 clock 37.88KHz v: height 600 start 601 end 605 total 628 clock 60.32Hz 640x480 (0x61) 31.500MHz -HSync -VSync h: width 640 start 656 end 720 total 840 skew 0 clock 37.50KHz v: height 480 start 481 end 484 total 500 clock 75.00Hz 640x480 (0x63) 25.175MHz -HSync -VSync h: width 640 start 656 end 752 total 800 skew 0 clock 31.47KHz v: height 480 start 490 end 492 total 525 clock 59.94Hz 720x400 (0x64) 28.320MHz -HSync +VSync h: width 720 start 738 end 846 total 900 skew 0 clock 31.47KHz v: height 400 start 412 end 414 total 449 clock 70.08Hz HDMI1 disconnected (normal left inverted right x axis y axis) Identifier: 0x43 Timestamp: 348006 Subpixel: unknown Clones: CRTCs: 1 2 Transform: 1.000000 0.000000 0.000000 0.000000 1.000000 0.000000 0.000000 0.000000 1.000000 filter: content type: No Data supported: No Data, Graphics, Photo, Cinema, Game aspect ratio: Automatic supported: Automatic, 4:3, 16:9 Broadcast RGB: Automatic supported: Automatic, Full, Limited 16:235 audio: auto supported: force-dvi, off, auto, on non-desktop: 0 range: (0, 1) link-status: Good supported: Good, Bad DP2 disconnected (normal left inverted right x axis y axis) Identifier: 0x44 Timestamp: 348006 Subpixel: unknown Clones: CRTCs: 0 Transform: 1.000000 0.000000 0.000000 0.000000 1.000000 0.000000 0.000000 0.000000 1.000000 filter: max bpc: 10 range: (6, 10) Broadcast RGB: Automatic supported: Automatic, Full, Limited 16:235 audio: auto supported: force-dvi, off, auto, on non-desktop: 0 range: (0, 1) link-status: Good supported: Good, Bad HDMI2 connected primary 1920x1080+0+0 (0x47) normal (normal left inverted right x axis y axis) 476mm x 268mm Identifier: 0x45 Timestamp: 348006 Subpixel: unknown Gamma: 1.0:1.0:1.0 Brightness: 1.0 Clones: CRTC: 0 CRTCs: 0 Transform: 1.000000 0.000000 0.000000 0.000000 1.000000 0.000000 0.000000 0.000000 1.000000 filter: _MUTTER_PRESENTATION_OUTPUT: 0 EDID: 00ffffffffffff0009d1e87845540101 141c010380301b782e79a5a85551a227 105054a56b80d1c0b300a9c081808100 81c001010101023a801871382d40582c 4500dc0c1100001e000000ff00455442 354a3032353439534c30000000fd0032 4c1e5311000a202020202020000000fc 0042656e51204757323238300a2001cb 020322f14f901f041303120211011406 07151605230907078301000065030c00 2000023a801871382d40582c4500dc0c 1100001e011d8018711c1620582c2500 dc0c1100009e011d007251d01e206e28 5500dc0c1100001e8c0ad08a20e02d10 103e9600dc0c11000018000000000000 00000000000000000000000000000071 content type: No Data supported: No Data, Graphics, Photo, Cinema, Game aspect ratio: Automatic supported: Automatic, 4:3, 16:9 Broadcast RGB: Automatic supported: Automatic, Full, Limited 16:235 audio: auto supported: force-dvi, off, auto, on non-desktop: 0 range: (0, 1) link-status: Good supported: Good, Bad 1920x1080 (0x47) 148.500MHz +HSync +VSync *current +preferred h: width 1920 start 2008 end 2052 total 2200 skew 0 clock 67.50KHz v: height 1080 start 1084 end 1089 total 1125 clock 60.00Hz 1920x1080 (0x48) 148.500MHz +HSync +VSync h: width 1920 start 2448 end 2492 total 2640 skew 0 clock 56.25KHz v: height 1080 start 1084 end 1089 total 1125 clock 50.00Hz 1920x1080 (0x49) 148.352MHz +HSync +VSync h: width 1920 start 2008 end 2052 total 2200 skew 0 clock 67.43KHz v: height 1080 start 1084 end 1089 total 1125 clock 59.94Hz 1920x1080i (0x4a) 74.250MHz +HSync +VSync Interlace h: width 1920 start 2008 end 2052 total 2200 skew 0 clock 33.75KHz v: height 1080 start 1084 end 1094 total 1125 clock 60.00Hz 1920x1080i (0x4b) 74.250MHz +HSync +VSync Interlace h: width 1920 start 2448 end 2492 total 2640 skew 0 clock 28.12KHz v: height 1080 start 1084 end 1094 total 1125 clock 50.00Hz 1920x1080i (0x4c) 74.176MHz +HSync +VSync Interlace h: width 1920 start 2008 end 2052 total 2200 skew 0 clock 33.72KHz v: height 1080 start 1084 end 1094 total 1125 clock 59.94Hz 1680x1050 (0x4d) 119.000MHz +HSync -VSync h: width 1680 start 1728 end 1760 total 1840 skew 0 clock 64.67KHz v: height 1050 start 1053 end 1059 total 1080 clock 59.88Hz 1600x900 (0x4e) 108.000MHz +HSync +VSync h: width 1600 start 1624 end 1704 total 1800 skew 0 clock 60.00KHz v: height 900 start 901 end 904 total 1000 clock 60.00Hz 1280x1024 (0x4f) 135.000MHz +HSync +VSync h: width 1280 start 1296 end 1440 total 1688 skew 0 clock 79.98KHz v: height 1024 start 1025 end 1028 total 1066 clock 75.02Hz 1280x1024 (0x50) 108.000MHz +HSync +VSync h: width 1280 start 1328 end 1440 total 1688 skew 0 clock 63.98KHz v: height 1024 start 1025 end 1028 total 1066 clock 60.02Hz 1280x800 (0x51) 71.000MHz +HSync -VSync h: width 1280 start 1328 end 1360 total 1440 skew 0 clock 49.31KHz v: height 800 start 803 end 809 total 823 clock 59.91Hz 1152x864 (0x52) 108.000MHz +HSync +VSync h: width 1152 start 1216 end 1344 total 1600 skew 0 clock 67.50KHz v: height 864 start 865 end 868 total 900 clock 75.00Hz 1280x720 (0x53) 74.250MHz +HSync +VSync h: width 1280 start 1390 end 1430 total 1650 skew 0 clock 45.00KHz v: height 720 start 725 end 730 total 750 clock 60.00Hz 1280x720 (0x54) 74.250MHz +HSync +VSync h: width 1280 start 1720 end 1760 total 1980 skew 0 clock 37.50KHz v: height 720 start 725 end 730 total 750 clock 50.00Hz 1280x720 (0x55) 74.176MHz +HSync +VSync h: width 1280 start 1390 end 1430 total 1650 skew 0 clock 44.96KHz v: height 720 start 725 end 730 total 750 clock 59.94Hz 1024x768 (0x56) 78.750MHz +HSync +VSync h: width 1024 start 1040 end 1136 total 1312 skew 0 clock 60.02KHz v: height 768 start 769 end 772 total 800 clock 75.03Hz 1024x768 (0x57) 65.000MHz -HSync -VSync h: width 1024 start 1048 end 1184 total 1344 skew 0 clock 48.36KHz v: height 768 start 771 end 777 total 806 clock 60.00Hz 832x624 (0x58) 57.284MHz -HSync -VSync h: width 832 start 864 end 928 total 1152 skew 0 clock 49.73KHz v: height 624 start 625 end 628 total 667 clock 74.55Hz 800x600 (0x59) 49.500MHz +HSync +VSync h: width 800 start 816 end 896 total 1056 skew 0 clock 46.88KHz v: height 600 start 601 end 604 total 625 clock 75.00Hz 800x600 (0x5a) 40.000MHz +HSync +VSync h: width 800 start 840 end 968 total 1056 skew 0 clock 37.88KHz v: height 600 start 601 end 605 total 628 clock 60.32Hz 720x576 (0x5b) 27.000MHz -HSync -VSync h: width 720 start 732 end 796 total 864 skew 0 clock 31.25KHz v: height 576 start 581 end 586 total 625 clock 50.00Hz 720x576i (0x5c) 13.500MHz -HSync -VSync Interlace h: width 720 start 732 end 795 total 864 skew 0 clock 15.62KHz v: height 576 start 580 end 586 total 625 clock 50.00Hz 720x480 (0x5d) 27.027MHz -HSync -VSync h: width 720 start 736 end 798 total 858 skew 0 clock 31.50KHz v: height 480 start 489 end 495 total 525 clock 60.00Hz 720x480 (0x5e) 27.000MHz -HSync -VSync h: width 720 start 736 end 798 total 858 skew 0 clock 31.47KHz v: height 480 start 489 end 495 total 525 clock 59.94Hz 720x480i (0x5f) 13.514MHz -HSync -VSync Interlace h: width 720 start 739 end 801 total 858 skew 0 clock 15.75KHz v: height 480 start 488 end 494 total 525 clock 60.00Hz 720x480i (0x60) 13.500MHz -HSync -VSync Interlace h: width 720 start 739 end 801 total 858 skew 0 clock 15.73KHz v: height 480 start 488 end 494 total 525 clock 59.94Hz 640x480 (0x61) 31.500MHz -HSync -VSync h: width 640 start 656 end 720 total 840 skew 0 clock 37.50KHz v: height 480 start 481 end 484 total 500 clock 75.00Hz 640x480 (0x62) 25.200MHz -HSync -VSync h: width 640 start 656 end 752 total 800 skew 0 clock 31.50KHz v: height 480 start 490 end 492 total 525 clock 60.00Hz 640x480 (0x63) 25.175MHz -HSync -VSync h: width 640 start 656 end 752 total 800 skew 0 clock 31.47KHz v: height 480 start 490 end 492 total 525 clock 59.94Hz 720x400 (0x64) 28.320MHz -HSync +VSync h: width 720 start 738 end 846 total 900 skew 0 clock 31.47KHz v: height 400 start 412 end 414 total 449 clock 70.08Hz
