I am trying to use my Canon DSLR as a webcam, on an Ubuntu machine. The camera does not show up as /dev/video*.
The camera shows up in hwinfo --usb:
19: USB 00.0: 10f01 WebCam [Created at usb.122] Unique ID: R8DB._ROX1vreGqF Parent ID: FKGF.4Nx_qoDfSd7 SysFS ID: /devices/pci0000:00/0000:00:1d.0/usb2/2-1/2-1.1/2-1.1:1.0 SysFS BusID: 2-1.1:1.0 Hardware Class: camera Model: "Canon EOS 100D" Hotplug: USB Vendor: usb 0x04a9 "Canon" Device: usb 0x3270 "EOS 100D" Revision: "0.02" Driver: "usbfs" Driver Modules: "usbcore" Speed: 480 Mbps Module Alias: "usb:v04A9p3270d0002dc00dsc00dp00ic06isc01ip01in00" Config Status: cfg=new, avail=yes, need=no, active=unknown Attached to: #4 (Hub) USB-related lsmod shows this:
$ lsmod | grep usb wusbcore 45056 0 # I activated this manually, shot in the dark uwb 73728 1 wusbcore snd_usb_audio 204800 4 snd_usbmidi_lib 32768 1 snd_usb_audio snd_hwdep 20480 2 snd_usb_audio,snd_hda_codec btusb 45056 0 btrtl 16384 1 btusb btbcm 16384 1 btusb btintel 16384 1 btusb bluetooth 548864 46 btrtl,hidp,btintel,btbcm,bnep,btusb,rfcomm snd_pcm 98304 5 snd_hda_codec_hdmi,snd_hda_intel,snd_usb_audio,snd_hda_codec,snd_hda_core snd_rawmidi 32768 2 snd_seq_midi,snd_usbmidi_lib snd 81920 34 snd_hda_codec_generic,snd_seq,snd_seq_device,snd_hda_codec_hdmi,snd_hwdep,snd_hda_intel,snd_usb_audio,snd_usbmidi_lib,snd_hda_codec,snd_hda_codec_realtek,snd_timer,snd_pcm,snd_rawmidi usbhid 49152 0 hid 118784 3 hidp,usbhid,hid_generic Here is the tail of dmesg:
[ 530.523684] media: Linux media interface: v0.10 [ 530.530299] Linux video capture interface: v2.00 [ 530.540171] usbcore: registered new interface driver uvcvideo [ 530.540172] USB Video Class driver (1.1.1) [ 878.930024] usb 2-1.1: USB disconnect, device number 6 [ 973.616657] usb 2-1.1: new high-speed USB device number 7 using ehci-pci [ 973.818855] usb 2-1.1: New USB device found, idVendor=04a9, idProduct=3270 [ 973.818859] usb 2-1.1: New USB device strings: Mfr=1, Product=2, SerialNumber=0 [ 973.818861] usb 2-1.1: Product: Canon Digital Camera [ 973.818862] usb 2-1.1: Manufacturer: Canon Inc. Trying to find something about usbcore to modprobe:
$ ls -R /lib/modules/$(uname -r)/kernel | grep usbcor wusbcore /lib/modules/4.15.0-91-generic/kernel/drivers/usb/wusbcore: wusbcore.ko As said before, the camera does not show up as /dev/video*, and I don't know what I should do next!
1 Answer
I got it working thanks to this:
$ sudo apt-get install gphoto2 v4l2loopback-utils ffmpeg $ sudo modprobe v4l2loopback exclusive_caps=1 max_buffers=2 (some advice there as how to make this more automatic) Then some running process needs to get killed:
$ ps aux|grep gphoto $ kill <the PID for the process gvfsd-gphoto2, or something like that> And running this in the background:
$ gphoto2 --stdout --capture-movie | ffmpeg -i - -vcodec rawvideo -pix_fmt yuv420p -threads 0 -f v4l2 /dev/video All this makes the /dev/video0 appear, and work as a video input. Although right now, I'm getting poor fps.
