The system runs Ubuntu 16.04.3 LTS with 3 1GBit NICs: one embedded and 2 Intel PCIe NICs. Both Intel NICs are bonded (bond0) with mode 4 (LACP). The switch is confugured to support LACP on these 2 ports. Here is the network configuration:
cat /etc/network/interfaces # This file describes the network interfaces available on your system # and how to activate them. For more information, see interfaces(5). source /etc/network/interfaces.d/* # The loopback network interface auto lo iface lo inet loopback # The primary network interface auto enp0s31f6 #iface enp0s31f6 inet dhcp iface enp0s31f6 inet static mtu 9000 address 192.168.x.x netmask 255.255.x.0 network 192.168.x.0 gateway 192.168.x.1 dns-nameservers 192.168.x.x auto enp3s0 iface enp3s0 inet manual bond-master bond0 auto enp4s0 iface enp4s0 inet manual bond-master bond0 auto bond0 iface bond0 inet static mtu 9000 address 192.168.x.x netmask 255.255.x.0 network 192.168.x.0 bond-mode 802.3ad bond-miimon 100 bond-lacp-rate 1 bond-slaves none This configuration runs rather well without errors. But if the network load is rather high (for instance, during copying 100-200 GB), the following errors are produced in /var/log/syslog:
Feb 14 17:20:02 ubuntu1 kernel: [29601.287684] e1000e: enp3s0 NIC Link is Down Feb 14 17:20:02 ubuntu1 kernel: [29601.287993] e1000e 0000:03:00.0 enp3s0: speed changed to 0 for port enp3s0 Feb 14 17:20:02 ubuntu1 kernel: [29601.379193] bond0: link status definitely down for interface enp3s0, disabling it Feb 14 17:20:02 ubuntu1 kernel: [29601.379199] bond0: first active interface up! Feb 14 17:20:04 ubuntu1 kernel: [29603.064712] e1000e: enp3s0 NIC Link is Up 1000 Mbps Full Duplex, Flow Control: Rx/Tx Feb 14 17:20:04 ubuntu1 kernel: [29603.079162] bond0: link status definitely up for interface enp3s0, 1000 Mbps full duplex Is it a known problem? Apparently after some seconds the failed interface works well again. The problem doesn't occur very often.
In the file /proc/net/bonding/bond0 I can see, that the mode 4 was correctly recognized:
cat /proc/net/bonding/bond0 Ethernet Channel Bonding Driver: v3.7.1 (April 27, 2011) Bonding Mode: IEEE 802.3ad Dynamic link aggregation Transmit Hash Policy: layer2 (0) MII Status: up MII Polling Interval (ms): 100 Up Delay (ms): 0 Down Delay (ms): 0 802.3ad info LACP rate: fast Min links: 0 Aggregator selection policy (ad_select): stable System priority: 65535 I have tried to use bond-slaves with interface names instead of none. But in this case the ifenslave was locked during restarting of network services. So I have found a recommendation, that using "none" the bond0 will be up and doesn't lock.
Any ideas?
