Let $f:\mathbb{R}^2 \to \mathbb{R}_+$ be the function defined piecewise by $$ f(x,y) := \begin{cases} \sqrt{1 - x^2 - y^2} &\text{, if } x^2+y^2 \leq 1 \text{ and } y \geq 0, \\ 0 &\text{, otherwise.} \end{cases} $$

I would like to plot this function in MATLAB. I tried the following code, but only recieve error notifications... (I suspect mistakes in the definition of f and/or the line with Z);

f = @(x,y) piecewise(x^2+y^2<=1, piecewise(y>=0,sqrt(1-x^2-y^2),y<0,0), x^2+y^2>1, 0); xarray = linspace(-5,5,51); yarray = linspace(-5,5,51); [X,Y] = meshgrid(xarray,yarray); Z = f(xarray,yarray); % Plot the function % figure surfc(X,Y,Z) xlabel('x') ylabel('y') zlabel('f(x,y)') colorbar

Thanks in advance for any help! :)

$\endgroup$2

1 Answer

$\begingroup$

Two different naive approaches (they are naive because they don't rigorously treat discontinuities):

xmin = -1.5; xmax = -xmin; xpto = 500; % creating 2D domain for your function.. ymin = -1.5; ymax = -ymin; ypto = 500; % creating 2D domain for your function.. [X,Y] = meshgrid(linspace(xmin,xmax,xpto),linspace(ymin,ymax,ypto)); % creating 2D domain for your function.. FXY_1 = sqrt(1-X.^2-Y.^2); % f1 values.. FXY_2 = 0*X; % f2 values.. FXY_1_CONDITION = ( X.^2 + Y.^2 ) <= 1 & Y >= 0; % f1 domain.. FXY_2_CONDITION = ~FXY_1_CONDITION; % f2 domain.. FXY_1(FXY_2_CONDITION) = NaN; % ignoring f2 domain in f1 (NaN values are ignored by plot function)... FXY_2(FXY_1_CONDITION) = NaN; % ignoring f1 domain in f2 (NaN values are ignored by plot function)... figure('color','white'); hold on; mesh(X,Y,FXY_1); % plot f1.. mesh(X,Y,FXY_2); % plot f2.. colorbar;

.

xmin = -1.5; xmax = -xmin; xpto = 500; % creating 2D domain for your function.. ymin = -1.5; ymax = -ymin; ypto = 500; % creating 2D domain for your function.. [X,Y] = meshgrid(linspace(xmin,xmax,xpto),linspace(ymin,ymax,ypto)); % creating 2D domain for your function.. FXY = NaN .* X; % initializing f.. FXY_1 = sqrt(1-X.^2-Y.^2); % f1 values.. FXY_2 = 0 .* X; % f2 values.. FXY_1_CONDITION = ( X.^2 + Y.^2 ) <= 1 & Y >= 0; % f1 domain.. FXY_2_CONDITION = ~FXY_1_CONDITION; % f2 domain.. FXY(FXY_1_CONDITION) = FXY_1(FXY_1_CONDITION); % passing f1 values to f.. FXY(FXY_2_CONDITION) = FXY_2(FXY_2_CONDITION); % passing f2 values to f.. figure('color','white'); mesh(X,Y,FXY); % plot f.. colorbar;
