How do I configure proxies without GUI?

How do you configure proxy settings in the Ubuntu Server or Minimal (CLI) versions using the terminal?

3 Answers

System-wide proxies in CLI Ubuntu/Server must be set as environment variables.

• Open the /etc/environment file with vi (or your favorite editor). This file stores the system-wide variables initialized upon boot.

• Add the following lines, modifying appropriately. You must duplicate in both upper-case and lower-case because (unfortunately) some programs only look for one or the other:

   http_proxy="" https_proxy="" ftp_proxy="" no_proxy="localhost,127.0.0.1,localaddress,.localdomain.com" HTTP_PROXY="" HTTPS_PROXY="" FTP_PROXY="" NO_PROXY="localhost,127.0.0.1,localaddress,.localdomain.com"

• apt-get, aptitude, etc. will not obey the environment variables when used normally with sudo. So separately configure them; create a file called 95proxies in /etc/apt/apt.conf.d/, and include the following:

   Acquire::http::proxy ""; Acquire::ftp::proxy "ftp://myproxy.server.com:8080/"; Acquire::https::proxy "";

Finally, logout and reboot to make sure the changes take effect.

Sources: 1, 2. See 1 in particular for additional help, including a script to quickly turn on/off the proxies.

If you have an authenticating proxy, then the URLs will be different. Instead of:

""

You'll have:

""

Note that these are still URLs, so passwords (and possibly usernames) will have to be URL encoded.

For example, a username of muru and a password of )qv3TB3LBm7EkP} would look like:

"):8080/"

This can be done in various ways:

1. There several websites for encoding:
   • etc.
2. Programmatic:
   • A bash script from Stack Overflow
   • In Perl, from Stack Overflow

In a pinch, you can use man url to see which characters need to be encoded:

An escaped octet is encoded as a character triplet, consisting of the percent character "%" followed by the two hexadecimal digits representing the octet code...

And the octet codes are available on man ascii.

 Proxy Environment Variables:

http_proxy: Proxy server for HTTP Traffic
https_proxy: Proxy server for HTTPS traffic
ftp_proxy: Proxy server for FTP traffic
no_proxy: Patterns for IP addresses or domain names that shouldn’t use the proxy

The value for every proxy setting, except for no_proxy, uses the same template. proxy_http=username:password@proxy-host:port

Temporary setting proxy: export HTTP_PROXY=user::8080

Persistent Proxy Settings: use vim ~/.bash_profile to open bash setup file, then put following lines inside it

export http_proxy=username::8080 export https_proxy=username::8081 export no_proxy=localhost, 127.0.0.1, *.my.lan

use source ~/.bash_profile to apply the changes
